Product Specification
| Model | Capacity (t) |
Control Voltage |
Power Supply |
No. of Chain Fall |
Insulation Class |
Lifting Motor (Inverter) |
Travelling Motor (Inverter) |
||||
| Lifting Speed (m/min) |
Motor Power (kw) |
Rotation Speed (r/min) |
Travelling Speed (m/min) |
Motor Power (kw) |
Rotation Speed (r/min) |
||||||
| 0.5-01ER | 0.5 | 24V/36V/48V | 3P 220V-525V 50/60Hz |
1 | F | 2.1-8.2 | 0.8 | 1440 | 3-11 or 19 | 0.4 | 1440 |
| 01-01ER | 1 | 1 | 1.8-7.2 | 1.5 | 0.4 | ||||||
| 01-02ER | 1 | 2 | 1.1-4.1 | 1.5 | 0.4 | ||||||
| 02-01ER | 2 | 1 | 1.8-7.2 | 3.3 | 0.4 | ||||||
| 02-02ER | 2 | 2 | 0.9-3.6 | 1.5 | 0.4 | ||||||
| 03-01ER | 3 | 1 | 1.8-5.6 | 3.3 | 0.4 | ||||||
| 03-02ER | 3 | 2 | 1.1-4.5 | 3.3 | 0.4 | ||||||
| 05-02ER | 5 | 2 | 0.8-3.3 | 3.3 | 0.4 | ||||||
Product Description
Our 1 ton ER Series Low Headroom Type Electric Chain Hoist is a top-of-the-line product that combines supreme efficiency, durability, and safety. This electric chain hoist is specifically designed for low headroom applications, making it an ideal solution for spaces with limited vertical clearance. With its advanced technology and sturdy construction, this hoist is capable of handling demanding lifting tasks with ease. Its smooth, precise operations ensure that your work is completed quickly and efficiently, making it perfect for demanding industrial environments. Its user-friendly design, advanced safety features, and reliable performance make it an excellent choice for any business looking for a top-quality hoist. Invest in our 1 ton ER Series Low Headroom Type Electric Chain Hoist and enjoy seamless, efficient, and safe lifting operations.
Product Features
- 1 ton load capacity: Can lift objects weighing up to 1 ton.
- ER Series: Designation for the electric chain hoist model series.
- Low Headroom Type: Specifically designed to operate in areas with low headroom clearance.
- Electric-powered: Runs on electricity, eliminating the need for manual labor to lift heavy objects.
- Expandable core: The hoist’s core can be extracted without expansion, making servicing and maintenance easier.
Application of 1 ton ER Series Low Headroom Type Electric Chain Hoist
- Effortlessly lift and move heavy loads up to 1 ton.
- Low headroom design makes it perfect for use in tight spaces.
- Electrically powered for convenience and ease of use.
- Chain hoist is durable and built to withstand heavy use.
- Suitable for use in a variety of industries including construction and manufacturing.
